Thursday, March 29, 2018

When You Listen to Katydids, Listen for the Rhythm








Cricket songs are a combination of pitch, rhythm, and phrase length. In the last post, we listened to tree crickets that sing on similar pitches to those of bird song. Even some of the very high cricket songs were still within the frequency ranges of the highest bird songs.

Not so with katydids. These songs are much higher, and their complex frequencies never sound like clear pitches. These insects are the percussion ensemble of the insect orchestra, so we’re going to focus on rhythm, song length, and dynamics (how loud and soft they sound).

If I want to imitate a katydid song, I'd choose a percussion instrument to create a non-pitched sound and I'd play the insect's rhythmic pattern.
To illustrate, I made a recording using a cabasa (an African/Brazilian percussion instrument) to create a sound reminiscent of the Common True Katydid. Let's see - and hear - how closely I can suggest their  actual songs.




Next, let’s look at the frequency range of katydid songs. (If you’d like a review of terminology such a frequency and Hz, please refer back to my previous post on cricket song.) The crickets of NE Ohio cover a frequency span ranging from about 2000 Hz (in the Tufted Titmouse range) up to about 7500 Hz (Grasshopper Sparrow and Cedar Waxwing range).

With the exception of the Common True Katydid, the katydids pick up where the crickets leave off and continue upward to the threshold of human hearing and even a little beyond. Please note that although “the threshold of human hearing” is typically listed at 20,000 Hz, the humans hearing those frequencies are probably young children.

Yes, it’s a fact. Over time, katydid songs become less accessible to our aging ears, though we may not notice right away since people don’t typically pay attention to such high frequencies.

The upper frequencies we do notice are the consonants of human speech. That’s what we first begin to lose when we become aware of a decrease in our hearing. Those missing consonants are much higher than vowels.

I created the example below to illustrate the frequencies of some of the highest consonants – the ones that sound similar to katydid songs. It's a recording of yours truly making consonant sounds such as “tic-tic-tic,” “tsit-tsit-tist” and both light and more aggressive high hissing. The frequencies approach those of many katydids; I even managed to get above 10,000 Hz at times.





But the last thing I want to do is discourage anyone before I’ve even gotten to my first katydid species. I’ll start with the katydid that has the lowest frequency song and is also quite loud: the Common True Katydid.



When people think of katydids, this is the species that comes to mind. The rhythm of their raspy songs suggests “Ka-ty-did! Ka-ty-did!” or “Ka-ty! Ka-ty!” and sometimes “Ka-ty did-n’t!” if it sounds like four syllables instead of two or three.

Look at the frequencies represented by the sonogram of the Common True Katydid recording. (Keep in mind that “frequency” refers to pitch, not how often the song occurs.) The loudest frequencies of this song start at around 3000 Hz, which is right in the range of the tree crickets. But what a difference in the tone quality!


That’s because there are so many overtones, or harmonics, above the lowest frequencies of the song. Simple bird songs like those of the Black-capped Chickadee appear as a solid, bright, narrow, white lines on the sonogram. Compare this with the White-breasted Nuthatch's buzzier, raspier song. There are many more overtones visible in the fuzzy, wide, dense image.



Look again at the Common True Katydid’s song: those overtones extend almost to the top of that five-year-old human’s hearing range. While few of us will hear all of those overtones, we will perceive this song as a dense, raspy, percussive sound rather than a clear pitch.

Now compare the clear pitch of a Broad-winged Tree Cricket to the raspy sound of the Common True Katydids. You'll see from the sonogrm that the katydid's overtones extend far up toward the limit of human hearing, even though the main frequences are in the same range as those of the tree cricket.





Let’s stay with the Common True Katydid for a little longer.


I’ve talked about the frequency range and the tone quality of his song. I’ve said that it’s loud, but you probably already knew that. I’ve also used a mnemonic device to indicate the rhythmic pattern: “Ka-ty-did! Ka-ty! Ka-ty!”

Do you remember my very important point about how temperature affects cricket songs – that these songs are faster and higher when it’s warm and slower and lower in pitch when temperatures are cooler? The same applies to katydids.

We don’t hear the pitches as clearly because they are high and complex (all those overtones), but we’ll still notice that they seem lower – or even just easier to hear – when temperatures drop. But even more than pitch, it's the tempo  that will be the primary indication of cool temperatures slowing down the insects’ abilities to produce songs.


Listen to the Common True Katydids in the first half of this recording. You likely can hear how fast they were singing on that 84-degree evening. But in the second half of the recording, it was only 55 degrees.  It sounded like they could barely move their wings as they groaned, “I’m so cold. Freezing! Freezing!” Late in the season, it’s “I’m still here.” “So am I.” “Me, too.” “Bare-ly.”




Here's another example. The Sword-bearing Conehead's song is a seemingly endless, rapid string of “tst-tst-tst-tsts.” But when the temperature drops down to about 60 degrees, the tempo gets significantly slower until he finally…just…stops.



The entire singing insect chorus– crickets AND katydids together – will speed up and slow down as an ensemble. The pitch drops as well, but it’s the tempo change that will be immediately obvious.


Although we can’t clearly identify the pitches of katydid songs, there is considerable variety in the rhythm and complexity.

The Fork-tailed Bush Katydid's is very simple song: it's basically just “Pffftt!” followed by a considerable pause, then another “Pffftt!”



The Greater Angle-wing's song is a series of “tic-tic-tic-tics” that starts slower and increases in speed towards its conclusion as his wings move closer together. Again, look at the sonogram. He can also make an emphatic “Tsit!” call. (The two-layer image shows the volume level- amplitude - in green and frequency in rose/orange.)




The Northern Bush Katydid has a complex song that some of us may find quite difficult to hear because it's very high.






Listening for rhythmic patterns is very helpful with all but the smallest katydids. For example, a meadow or meadow edge will likely have an abundant number of conehead katydids. Cleveland/Akron and east will have a plethora of Sword-bearing Coneheads and also some Round-tipped Coneheads (a southern Ohio species that has moved north into our area). Lorain and Medina counties will have Nebraska Coneheads as well.

A reliable way to visually distinguish between conehead species is to look at the shape of the cone at the tip of their heads and then determine how much black is on that cone. You’d need to do that at night, and the coneheads would need to allow you to get close enough to inspect their cones. I can assure you they will have no interest in assisting you with this.

 Sword-bearing Conehead

Or…you can listen to their songs from a respectful distance so they don’t drop head first (really, cone first) into the vegetation or indignantly fly away.
Listen for the rhythmic pattern: a rapid, non-stop “tst-tst-tst-tst” (Sword-bearing Conehead), a continuous, penetrating, electrical buzz (Round-tipped Conehead), or a steady alternation between abrasive buzzes and pauses (Nebraska Conehead).


I’d recommend the latter approach.

Songs will be very helpful for other species that are visually similar. The Rattler Round-winged Katydid and the Oblong-winged Katydid resemble each other and can be found in the same understory and woodland edge habitat. The Oblong-winged is larger, has a very dark stridulatory field, and has longer wings, but you may not be able to see the katydid at the most helpful angle to observe all his details. You also are highly unlikely to have the two species next to each other so you can compare size. (Have you ever wondered if you’re looking at a Downy Woodpecker or a Hairy Woodpecker? And did they pose next to each other to make it easier for you?)

  Rattler Round-winged Katydid

If the katydid is a male, the song will answer the question. If you see a female, perhaps you’ll hear a nearby male’s song. If you've identified him by song, compare her size and shape to his. It will be similar.


The first song is the Rattler Round-winged, and the second song, which is short and emphatic, is the Oblong-winged.

Oblong-winged Katydid



The Scudderia bush katydids often look very similar, and the songs take a little more time to learn. There’s hope, though. You’ll be able to tell them apart with a little time and practice. This recording illustrates one song possibility each from two very common species: the Curve-tailed Bush Katydid and the Texas Bush Katydid. They can be found together in the same meadow habitats in late summer into the fall.

      Texas Bush Katydid




Meadow katydids are smaller than the others I’ve discussed, and their very high songs can seem inaccessibly soft to our ears. Those in the genus Orchelimum can be differentiated with a little practice not only by song but also by habitat and season. We only have two widespread species –the early-summer Gladiator Meadow Katydid followed (and eventually replaced) by the widespread Black-legged Meadow Katydid. Common Meadow Katydids actually not common, in fact, but you're probably more likely to find them in Medina and Lorain counties.

Black-legged Meadow Katydid



The diminutive meadow katydids in the genus Conocephalus will be a greater challenge because their songs are even lighter and higher. In addition, they all sing a variety of tics and whirrs, and their upper frequencies may extend above what even young humans can hear. Fortunately, these katydids are active during the afternoon as well as at night, so you’ll be able see them even if hearing them is difficult. The most common species in our area is the Short-winged Meadow Katydid.

Short-winged Meadow Katydid



There are other gorgeous and intriguing katydids that I haven’t mentioned in this introduction to listening, but be assured that I’ll discuss all of them in subsequent posts.

For now, three important things to remember are:

You’ll need to listen for the rhythm, because you won’t hear their complex, percussive-sounding songs as musical pitches.

They sing faster when they are warm and slower when colder. On a chilly night, they can almost sound like a different species.

They don’t all sing in the same habitat, and some sing earlier in the season than others. This will help limit your choices.

And finally, as with birdsong: please don’t try to learn all of them at once! Start with the most common and most audible. Add more each year, and expect that you’ll need to review the ones you learned last year after you haven’t heard them for many months. You probably have to review some of the songs of migrating warblers in the spring, don’t you?

In a year or two, you’ll walk out on a summer evening, hear an ensemble of crickets and katydids, and recognize the primary instrument groups. Eventually, you’ll find you know most of the individual musicians. Summer and early autumn will never sound the same!

Monday, March 19, 2018

Cricket Songs: General Characteristics of Pitch and Rhythm



Having looked - and listened – to how crickets and katydids sing, the next step is to explore the nature of their songs. We’ll get more specific later, but I think it’s essential to know the general characteristics first. I’m going to focus on two basic musical elements: pitch and rhythm


Let’s start with the crickets. We can often hear crickets more clearly and more easily because their songs are actually much lower in pitch than most of the katydids. (We’ll explore katydid songs in the next post.)


Pitch


Insect song is not like birdsong. Unlike most songbirds, crickets do not change pitch during the course of a song. They do not create little melodies. (Slowing down their pitches will not create “God’s Cricket Chorus,” no matter what you may have encountered on Facebook.)


Here’s an example:







Notice that the Tufted Titmouse song has two different pitches. It’s a simple song that we could imitate – just in a lower octave than the Titmouse because we humans can’t sing that high.



One pitch is higher than the other, and the two notes alternate in a simple higher-lower pattern. The rhythm of this short song is repetitious, and then there’s a short pause. After this brief rest, the Titmouse sings the song again (and again and again).


The Snowy Tree Cricket has a pitch that we could also imitate as long as we sing it in a lower octave.  But notice that I said “a pitch.” Just one. The cricket can’t change pitches in the course of his song like the Titmouse. He can repeat his single note at a very steady rhythm, but it’s just one pitch.



You can see the higher-lower alternation of the Titmouse song in the sonogram, and you’ll also see that the Snowy Tree cricket’s song is a repetition of the same note at a steady rhythmic pace.



As with birds, different species sing at higher or lower pitches from each other. Before we take a look and listen to the wide range covered by all NE Ohio's cricket species as a group, let's start with a quick terminology clarification.

I’ll be referring to “frequency,” which is a specific indication of how high or low a pitch is, not how often it occurs. The term “hertz” is used as a measure of frequency. 3000 hertz means 3000 cycles per second and is abbreviated as 3000 Hz or 3 kHz – kilohertz.

I’ll make this more accessible by providing birdsong, human voice, and even piano comparisons to provide a concrete context. For example, middle C on the piano is 261.6 Hz. My general singing voice range is between about 220 and 880 Hz. We’re going to be listening to singers whose performances are far higher than those of humans!



Tree cricket songs resemble the pitch range and clarity of birdsong, which is why I paired the Tufted Titmouse with the Snowy Tree Cricket in my earlier example. These crickets sing between about 2500 and 4000 Hz, and common birds such as the Black-capped Chickadee, Tufted Titmouse, Eastern Bluebird, and Baltimore Oriole sing in the same range. The lower of the two notes in the Titmouse song recording was almost identical to the Snowy Tree Cricket's single pitch: about 3000 Hz.

I’ve recorded Field Sparrows whose songs ascend from about 3500 Hz up to a little above 4000 Hz. Listen to an example of a Four-spotted Tree Cricket singing at about 4000 Hz followed by a Field Sparrow’s song in the same range:








We’re going to listen to smaller crickets with higher songs next. All of them sing above the highest note on the piano, which is only 4186 Hz.


The tiny trigs - just ¼-1/3 inch in size - sound about an octave higher than the tree crickets, ranging between 6000 Hz for the Spring Trig up to around 7000 Hz and above for the Say’s and Handsome Trigs (pictured below.)

Handsome Trig singing





Although quite high, these songs still sound like musical notes. Bird songs in similar ranges include the Grasshopper Sparrow, Henslow’s Sparrow, and Cedar Waxwings (pictured).






Ground crickets also sing much higher than tree crickets. Their songs are between 6000 and 7500 Hz. In addition to being very high, many of them sound less musical because the tone quality is buzzier to our ears. The most musical among them – at least in our region – is the Allard’s Ground Cricket with his rapid, sparkling song. The Striped Ground Cricket has a more buzzy sound and a steady, rhythmic "zit-zit-zit" song. This is an Allard's (pictured) and a Striped singing together.








Finally, here’s a representative example of the entire range of cricket song in NE Ohio: an example that strings together a Mole Cricket, Narrow-winged Tree Cricket, Black-horned Tree Cricket, Spring Trig, Allard’s Ground Cricket, and Say’s Trig.






Rhythm and phrasing


It’s all about rhythm and phrasing with insect songs. Many cricket species have rhythmic patterns we can learn to recognize. Others have long songs that are a continuous stream of very fast notes called a “trill.”

The Fall Field Cricket and the Jumping Bush Cricket both sing a long series of chirps that may even occur at the same pitch, depending on temperature. What’s the difference? The Fall Field Cricket’s songs will be much faster and have less space between them than those of the Jumping Bush Cricket. (Both are singing at around 5000 Hz in this particular track. Photo: Fall Field Crickets.)





Here’s a Snowy Tree Cricket followed by a Narrow-winged Tree Cricket (photo below). Their distinctly different rhythmic patterns help us identify them in the field, which is helpful because they may be in the same habitat or even in the same tree or shrub.







The Broad-winged Tree Cricket sings a long, very fast, continuous trill without rhythmic pauses; the pitch, as you would expect by now, stays the same throughout. Black-horned and Forbes’s Tree crickets (which look and sound identical) also sing continuous trills, as do Pine Tree Crickets and Four-spotted tree Crickets. This group is a challenge because they do not have rhythmic patterns that help us identify them when we can’t see them, and we’ll address that challenge in greater detail when we explore groups of similar species.


Finally, listen to these three common ground crickets: the Carolina Ground Cricket, the Allard's Ground Cricket, and the Striped Ground Cricket. They look so similar that it takes a great deal of practice to tell them apart. However, the rhythm of their songs makes the different species quite obvious!






Temperature changes everyone’s pitch and tempo!


Finally, the pitch of all these crickets will be higher in warm temperatures and lower in cool temperatures. Keep in mind that they are cold-blooded individuals. They move much more quickly when it’s quite warm. They can run and jump faster, and they can also move their wings faster and sing higher.

It’s important to remember that temperature affects all of the crickets and katydids.  The entire insect orchestra will sing faster and higher when warm. As temperatures drop at night, the entire ensemble sings slower and at a lower pitch.

This is the reason we cannot identify crickets by their pitches. The pitch you will hear in a field guide recording is only true at the same temperature as when the recording was made. Here are some examples:


The first is a Snowy Tree Cricket singing at 84F, then 66F, and finally at 61F.



Did you notice that the second and third series of songs were  both slower in tempo and lower in pitch? For this species, you can even calculate the temperature by counting the number of chirps in 13 seconds and then adding 40.

If the temperature is not identical on two adjacent plants or a different part of the same shrub, that small difference will be revealed by the songs of two nearby individuals. In this recording, you’ll hear two nearby Snowy Tree Crickets in the same flowering raspberry singing almost – but not quite – the same pitches. They are not completely in sync rhythmically, either, because the one that’s a bit warmer is singing just a little faster. Yes, they are that sensitive to temperature! You'll hear each one separately, then both together.





Now listen to the difference in pitch between a Broad-winged Tree Cricket on a warm evening and another at 58 degrees. The frequency drops from 2637 Hz (an E) all the way down to 1661 Hz (a G#). At the colder temperature, it becomes possible to hear the separate wing strokes because he’s moving more slowly. He’s cold, but determined!






Here’s another example: a Jumping Bush Cricket on a warm, late-summer evening and then a chilly night (55F). As they sing slower (as well as lower in pitch), it becomes possible to better hear the individual wing strokes that make up each chirp.





This Pine Tree Cricket was struggling to sing when the night temperature dropped from 70F (beginning of this track) down to 61F (end of this track). Eventually, he could no longer continue his steady trill. He finally just stopped.







Finally, I have one last cricket/bird pairing to summarize. Remember that Four-spotted Tree Cricket recordings I paired with Field Sparrow?  The Four-spotted sings a continuous trill, but notice that it’s lower at the cooler temperatures and higher at warmer temperatures. The Field Sparrow (a species that would live in the same habitat as the Four-spotted Tree Cricket) has a song that can start lower and ascends. In just one song, the Field Sparrow covers the range of pitches that the Four-spotted sings at 66F all the way up to the 80 degrees. Birds can change pitches within a single song AND their pitches do not change with the temperature.







Our challenge is clear. Each song has just one pitch, but everyone’s pitches rise and fall together with temperature changes. We can’t assume that a recording of a particular cricket will match that same species in the field unless the temperatures are the same.  Rhythmic patterns are very helpful, so tree crickets that sing long, continuous trills are the biggest challenge. In future posts, I’ll offer more specific guidelines for these identifications when we talk about seasons and habitat.


                                Four-spotted Tree Cricket singing in aster flowers.
